Original 3 years Warranty by TP-Link Malaysia
Feature:
- Features 24 PoE ports, with total PoE power budget of 192W and useful PoE power management features
- Integrated security strategy including 802.1Q VLAN, Port Security and Storm control help protect LAN area investment
- L2/L3/L4 QoS and IGMP snooping optimize voice and video applications
- WEB/CLI managed modes, SNMP, RMON bring abundant management features
- Dual Firmware Image improves reliability and up-time of your network
HARDWARE FEATURES
Standards and Protocols:
•IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q,IEEE 802.1p
Interface:
• 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
• 4 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
• 2 Combo Gigabit SFP Slots
Network Media:
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
• 1000BASE-X: MMF, SMF
Fan Quantity: 2
Physical Security Lock: Yes
PoE Budget: 192W
Mounting: Rack Mountable
Max Power Consumption:
•21.7W (220V/50Hz with no PD connected)
•229.73W (110V/60Hz with 192W PD connected)
Max Heat Dissipation:
•74.04 BTU/h (with no PD connected)
•783.84 BTU/h (with 192W PD connected)
PERFORMANCE
Bandwidth/Backplane: 12.8Gbps
Packet Forwarding Rate: 9.5Mpps
MAC Address Table : 8k
Jumbo Frame: 9216 Bytes
Dimensions ( W x D x H )A
17.3*8.7*1.7 in.(440*220*44 mm)
Package Contents
1x T1500-28PCT
1x Power Cord
1x Installation Guide
1x Resource CD
1x Rackmount Kit
1x Rubber Feet
